Lincoln Aviator: Exterior Lighting / Removal and Installation - Headlamp Assembly

Removal and Installation - Front Turn Signal Lamp

Removal NOTE: Removal steps in this procedure may contain installation details. NOTE: LH front turn signal lamp shown, RH front turn signal lamp similar...

Removal and Installation - Headlamp Control Module (HCM)

Removal NOTE: This step is only necessary if the HCM is being replaced. NOTE: If installing a new module, it is necessary to upload the module configuration information to the scan tool prior to removing the module...

Other information:

Lincoln Aviator 2020-2025 Service Manual: Description and Operation - Vehicle Specific Body Construction

For recommended metal repair guidelines and recommendations, refer to the following illustrations and: For additional information, refer to: Specifications (501-25 Body Repairs - General Information, Specifications). Steel Type Legend Item Steel Type Color 1 Mild Steel Yellow 2 Bake Hardened Steel (BH) Light Blue 3 Solid Solution Strength Pink 4 High Strength Low Alloy (HSLA) Dark Blue 5 Dual Phase (DP) 500, 600 Class Steel Green 6 Dual Phase (DP) 700, 800, 900, 1000 Class Steel Fuchsia 7 Laminate Steel Teal 8 Ultra High Strength Steel (UHSS) Martensitic, Boron Red 9 Transformation Induced Plasticity Steel (TRIP) Gold 10 Aluminum Purple Front Structure Item Description Steel Type 1 Radiator support Magnesium alloy 2 Bracket High-Strength Low Alloy (HSLA) 350 steel 3 Bracket Aluminum alloy 4 Suspension housing Aluminum alloy 5 Reinforcement High-Strength Low Alloy (HSLA) 350 steel 6 Reinforcement Boron and Dual Phase (DP) 600 steel 7 Reinforcement Boron and Dual Phase (DP) 600 steel 8 Bracket Aluminum alloy 9 Side member assembly Aluminum alloy 10 Fender apron tube Dual Phase (DP) 800 steel Front Bumper Item Description Steel Type 1 Bumper assembly High strength aluminum Dash Panel and Front Fenders Item Description Steel Type 1 Crossmember Boron steel 2 Dash panel Mild steel 3 Cowl top panel Mild steel 4 Reinforcement Dual Phase (DP) 800 steel 5 Front crossmemembr extension Dual Phase (DP) 600 steel 6 Reinforcement Dual Phase (DP) 800 steel 7 Fender assembly (LH/RH) Bake Hardened (BH) 210 steel 8 Bracket Mild steel Body Side Inner Panels NOTE: Left hand (LH) side shown, right hand (RH) side similar...

Lincoln Aviator 2020-2025 Service Manual: Diagnosis and Testing - Trailer Lamps

Diagnostic Trouble Code (DTC) Chart Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).   Diagnostic Trouble Code Chart Module   DTC Description Action   BCM B1449:12 Trailer Tow Park/Tail Lamp Output: Circuit Short To Battery   GO to Pinpoint Test C   BCM B1449:14 Trailer Tow Park/Tail Lamp Output: Circuit Short To Ground or Open   GO to Pinpoint Test C   TRM B10E8:4B Secondary Battery Relay "A": Over Temperature   GO to Pinpoint Test E   TRM B1D08:11 Left Trailer Direction Indicator: Circuit Short To Ground   GO to Pinpoint Test B   TRM B1D08:12 Left Trailer Direction Indicator: Circuit Short To Battery   GO to Pinpoint Test B   TRM B1D09:11 Right Trailer Direction Indicator: Circuit Short To Ground   GO to Pinpoint Test B   TRM B1D09:12 Right Trailer Direction Indicator: Circuit Short To Battery   GO to Pinpoint Test B   TRM U0140:00 Lost Communication With Body Control Module: No Sub-Type Information   GO to Pinpoint Test F   TRM U1000:00 Solid State Driver Protection Active -Driver Disabled: No Sub Type Information   GO to Pinpoint Test H   TRM U2100:00 Initial Configuration Not Complete: No Sub Type Information   GO to Pinpoint Test G   TRM U3000:49 Control Module: Internal Electronic Failure   GO to Pinpoint Test H Symptom Charts Symptom Chart: Trailer Lamps Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices...
