Diagnostic Trouble Code (DTC) Chart
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).
Diagnostic Trouble Code Chart
Module
DTC
Description
Action
PCM
P059F:00
Active Grille Air Shutter "A" Performance/Stuck Off:No Sub Type Information
GO to Pinpoint Test A
PCM
P05A1:00
Active Grille Air Shutter "A" Position
Sensor Minimum/Maximum Stop Performance:No Sub Type Information
GO to Pinpoint Test A
PCM
P05A2:00
Active Grille Air Shutter "A" Control Circuit/Open:No Sub Type Information
GO to Pinpoint Test A
PCM
P05A7:00
Active Grille Air Shutter "A" Supply Voltage Circuit Low:No Sub Type Information
GO to Pinpoint Test A
PCM
P05AE:00
Active Grille Air Shutter "B" Performance/Stuck Off:No Sub Type Information
GO to Pinpoint Test A
PCM
P05B0:00
Active Grille Air Shutter "B" Position
Sensor Minimum/Maximum Stop Performance:No Sub Type Information
GO to Pinpoint Test A
PCM
P05B1:00
Active Grille Air Shutter "B" Control Circuit/Open:No Sub Type Information
GO to Pinpoint Test A
PCM
P05B6:00
Active Grille Air Shutter "B" Supply Voltage Circuit Low:No Sub Type Information
GO to Pinpoint Test A
PCM
P05C0:00
Active Grille Air Shutter Module "A" Over Temperature:No Sub Type Information
GO to Pinpoint Test A
PCM
P05C1:00
Active Grille Air Shutter Module "B" Over Temperature:No Sub Type Information
GO to Pinpoint Test A
PCM
U0046:00
Vehicle Communication Bus C:No Sub Type Information
GO to Pinpoint Test A
PCM
U0284:00
Lost Communication with Active Grille Air Shutter Module "A":No Sub Type Information
GO to Pinpoint Test A
PCM
U0285:00
Lost Communication with Active Grille Air Shutter Module "B":No Sub Type Information
GO to Pinpoint Test A
Symptom Chart(s)
Symptom Chart: Active Grille Shutter
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices...
System Operation
System Diagram
NOTE:
The system diagrams include all component options. Some components may not be equipped on the vehicle.
Audio System - 10 Speaker System
Item
Description
1
APIM
2
AM/ FM1 Antenna Amplifier
3
Display Unit
4
GWM
5
BCM
6
ACM
7
FCIMB
8
IPC
9
GPS/Satellite Radio Antenna
10
RACM
11
Speakers
12
PCM
13
Audio/SYNC Switches
14
SIMA
15
FM2 Antenna Amplifier
16
SCCM
17
Subwoofer Amplifier and Speaker
Audio System - 14 or 28 Speaker System
Item
Description
1
APIM
2
Display Unit
3
GWM
4
BCM
5
ACM
6
FM2 Antenna Amplifier
7
DSP
8
IPC
9
Satellite/GPS Antenna
10
AM/ FM1 Antenna Amplifier
11
ANC Microphones
12
PCM
13
Speakers
14
SCCM
15
Audio/SYNC Switches
16
SIMA
17
FCIMB
SYNC System
Item
Description
1
Roof Antenna
2
APIM
3
Display Unit
4
Media Hub
5
Microphone
6
ABS Module
7
RCM
8
GWM
9
BCM
10
PCM
11
IPC
12
FCIMB
13
ACM
14
Wi-Fi Device
15
Bluetooth Device
16
DSP
17
ACM
18
Speakers
19
TCU
20
TCU Antenna
21
Wi-Fi Device
22
SCCM
23
Audio/SYNC Switches
24
SIMA
25
GPS/Satellite Radio Antenna
26
Cellular Antenna
Network Message Chart
ACM Network Input Messages
Broadcast Message
Originating Module
Message Purpose
Accelerator pedal position
PCM
Uses the accelerator pedal position percentage for the ANC system operation...
